Hi coders
I am new to pytorch as I have just started today, I saw few examples in kaggle and try to adapt my cnn from tensorflow in torch to enable better gpu allocation. However, I am stuck in a shape problem
I want to balance the data in train and test dataset so I have used train_test_split, have I applied it in the correct way although it is not giving an error
Could someone help please?
I have defined the customdataset in other python file and importing it in the main module
class CustomDataset(Dataset):
def __init__(self, root_folder_path):
self.root_folder_path = root_folder_path
self.image_files = []
self.labels = []
# Collect image paths and corresponding labels
folders = sorted([f for f in os.listdir(root_folder_path) if os.path.isdir(os.path.join(root_folder_path, f))])
self.label_dict = {folder: i for i, folder in enumerate(folders)}
for folder in folders:
folder_path = os.path.join(root_folder_path, folder)
image_files = sorted([f for f in os.listdir(folder_path) if os.path.isfile(os.path.join(folder_path, f)) and f.endswith('.jpg')])
self.image_files.extend([os.path.join(folder_path, img) for img in image_files])
self.labels.extend([self.label_dict[folder]] * len(image_files))
self.transform = transforms.Compose([
transforms.ToPILImage(),
transforms.Resize((900, 300)),
transforms.Grayscale(),
transforms.ToTensor(),
transforms.Normalize(mean=[0.5], std=[0.5])
])
def __len__(self):
return len(self.image_files)
def __getitem__(self, idx):
image_path = self.image_files[idx]
label = self.labels[idx]
image = cv2.imread(image_path, cv2.IMREAD_GRAYSCALE)
image = self.transform(image)
return image, label
this is my main script
if __name__ == '__main__':
# Instantiate your custom dataset and dataloaders
root_folder_path = r'W:\MASTER_BAGCHI_SCHALDACH\THESIS\code and dataset\image_dataset_300_900_10_classes'
dataset = CustomDataset(root_folder_path)
print("Labels:", sorted(dataset.label_dict.keys()))
print("Total number of labels:", len(dataset.label_dict))
# Display some images from each folder
n_images_to_display = 4
n_folders = len(dataset.label_dict)
fig, ax = plt.subplots(n_images_to_display, n_folders, figsize=(n_folders * 4, n_images_to_display * 4))
for i, (folder, label) in enumerate(dataset.label_dict.items()):
folder_images = [dataset[i][0] for i, lbl in enumerate(dataset.labels) if lbl == label]
indices_to_display = random.sample(range(len(folder_images)), min(n_images_to_display, len(folder_images)))
for j, ind in enumerate(indices_to_display):
ax[j, i].imshow(folder_images[ind].squeeze(), cmap='gray') # Squeeze to remove the channel dimension for grayscale images
ax[j, i].axis('off')
ax[0, i].set_title(folder, fontsize=30)
plt.show()
fig.tight_layout(pad=0, w_pad=0, h_pad=0)
from torch.utils.data import DataLoader, Subset
from sklearn.model_selection import train_test_split
TEST_SIZE = 0.2
BATCH_SIZE = 64
SEED = 42
# Get the labels from the dataset
labels = np.array([label for _, label in dataset])
# generate indices: instead of the actual data we pass in integers instead
train_indices, test_indices, _, _ = train_test_split(
range(len(dataset)),
labels,
stratify=labels,
test_size=TEST_SIZE,
random_state=SEED
)
# generate subset based on indices
train_split = Subset(dataset, train_indices)
test_split = Subset(dataset, test_indices)
print('Length of train_batch:',len(train_split))
print('Length of test_batch:',len(test_split))
# create batches
train_loader = DataLoader(train_split, batch_size=BATCH_SIZE, num_workers=6,shuffle=True,pin_memory=True)
test_loader = DataLoader(test_split, batch_size=BATCH_SIZE,num_workers=6,pin_memory=True)
class ImageClassificationBase(nn.Module):
def training_step(self, batch):
images, labels = batch
out = self(images) # Generate predictions
loss = F.cross_entropy(out, labels) # Calculate loss
return loss
def accuracy(outputs, labels):
_, preds = torch.max(outputs, dim=1)
return torch.tensor(torch.sum(preds == labels).item() / len(preds))
def validation_step(self, batch):
images, labels = batch
out = self(images) # Generate predictions
loss = F.cross_entropy(out, labels) # Calculate loss
acc = accuracy(out, labels) # Calculate accuracy
return {'val_loss': loss.detach(), 'val_acc': acc}
def validation_epoch_end(self, outputs):
batch_losses = [x['val_loss'] for x in outputs]
epoch_loss = torch.stack(batch_losses).mean() # Combine losses
batch_accs = [x['val_acc'] for x in outputs]
epoch_acc = torch.stack(batch_accs).mean() # Combine accuracies
return {'val_loss': epoch_loss.item(), 'val_acc': epoch_acc.item()}
def epoch_end(self, epoch, result):
print("Epoch [{}], train_loss: {:.4f}, val_loss: {:.4f}, val_acc: {:.4f}".format(
epoch, result['train_loss'], result['val_loss'], result['val_acc']))
import torch.nn.init as init
class ImageClassification(ImageClassificationBase):
def __init__(self):
super().__init__()
self.network = nn.Sequential(
#image size is [1,900,300] as [channel, height,width]
nn.Conv2d(1, 32, kernel_size = 3, padding = 1),
nn.LeakyReLU(0.01),
nn.BatchNorm2d(32),
nn.AvgPool2d(kernel_size=2, stride=2),
nn.Conv2d(32,32, kernel_size = 3, padding = 1),
nn.LeakyReLU(0.01),
nn.BatchNorm2d(32),
nn.AvgPool2d(kernel_size=2, stride=2),
nn.Conv2d(32, 64, kernel_size = 3, padding = 1),
nn.LeakyReLU(0.01),
nn.BatchNorm2d(64),
nn.AvgPool2d(kernel_size=2, stride=2),
nn.Conv2d(64 ,64, kernel_size = 3, padding = 1),
nn.LeakyReLU(0.01),
nn.BatchNorm2d(64),
nn.AvgPool2d(kernel_size=2, stride=2),
nn.Flatten(),
nn.Dropout(0.3),
nn.Linear(64 * 56 * 18, 64), # Assuming input size after convolutional layers is 64 * 56 * 18
nn.LeakyReLU(0.01),
nn.BatchNorm1d(64),
nn.Dropout(0.2),
nn.Linear(64, 64),
nn.LeakyReLU(0.01),
nn.BatchNorm1d(64),
nn.Dropout(0.2),
nn.Linear(64, 10) # Output layer
)
# Initialize the weights of convolutional layers
self._initialize_weights()
def _initialize_weights(self):
for m in self.modules():
if isinstance(m, nn.Conv2d):
init.kaiming_uniform_(m.weight, mode='fan_in', nonlinearity='leaky_relu')
def forward(self, xb):
return self.network(xb)
def get_default_device():
""" Set Device to GPU or CPU"""
if torch.cuda.is_available():
return torch.device('cuda')
else:
return torch.device('cpu')
def to_device(data, device):
"Move data to the device"
if isinstance(data,(list,tuple)):
return [to_device(x,device) for x in data]
return data.to(device,non_blocking = True)
class DeviceDataLoader():
""" Wrap a dataloader to move data to a device """
def __init__(self, dl, device):
self.dl = dl
self.device = device
def __iter__(self):
""" Yield a batch of data after moving it to device"""
for b in self.dl:
yield to_device(b,self.device)
def __len__(self):
""" Number of batches """
return len(self.dl)
device = get_default_device()
device
torch.cuda.empty_cache()
model = ImageClassification()
random_seed = 99
torch.manual_seed(random_seed)
train_loader = DeviceDataLoader(train_loader, device)
test_loader = DeviceDataLoader(test_loader, device)
to_device(model, device)
@torch.no_grad()
def evaluate(model, val_loader):
model.eval()
outputs = [model.validation_step(batch) for batch in val_loader]
return model.validation_epoch_end(outputs)
def accuracy(outputs, labels):
_, preds = torch.max(outputs, dim=1)
return torch.tensor(torch.sum(preds == labels).item() / len(preds))
def fit(epochs, lr, model, train_loader, val_loader, opt_func=torch.optim.RMSprop):
history = []
optimizer = opt_func(model.parameters(), lr)
for epoch in range(epochs):
# Training Phase
model.train()
train_losses = []
for batch in train_loader:
loss = model.training_step(batch)
train_losses.append(loss)
loss.backward()
optimizer.step()
optimizer.zero_grad()
# Validation phase
result = evaluate(model, val_loader)
result['train_loss'] = torch.stack(train_losses).mean().item()
model.epoch_end(epoch, result)
history.append(result)
return history
model=to_device(ImageClassification(),device)
#initial evaluation of the model
evaluate(model,test_loader)
data looks like this and my size of the image in the model is [1,900,300] where 1 stands for graychannel, 900 - height of the image in pixels, 300 - width of the image in pixels
and the error is
File "w:\MASTER_BAGCHI_SCHALDACH\THESIS\code and dataset\10 class cropped 300_900 runs\10_class_torch.py", line 236, in <module>
evaluate(model,test_loader)
File "C:\Users\smjobagc\AppData\Local\miniconda3\envs\FSV\lib\site-packages\torch\autograd\grad_mode.py", line 28, in decorate_context
return func(*args, **kwargs)
File "w:\MASTER_BAGCHI_SCHALDACH\THESIS\code and dataset\10 class cropped 300_900 runs\10_class_torch.py", line 206, in evaluate
outputs = [model.validation_step(batch) for batch in val_loader]
File "w:\MASTER_BAGCHI_SCHALDACH\THESIS\code and dataset\10 class cropped 300_900 runs\10_class_torch.py", line 206, in <listcomp>
outputs = [model.validation_step(batch) for batch in val_loader]
File "w:\MASTER_BAGCHI_SCHALDACH\THESIS\code and dataset\10 class cropped 300_900 runs\10_class_torch.py", line 92, in validation_step
acc = accuracy(out, labels) # Calculate accuracy
File "w:\MASTER_BAGCHI_SCHALDACH\THESIS\code and dataset\10 class cropped 300_900 runs\10_class_torch.py", line 211, in accuracy
return torch.tensor(torch.sum(preds == labels).item() / len(preds))
RuntimeError: The size of tensor a (64) must match the size of tensor b (10) at non-singleton dimension 1
Here is the drive link of the dataset: https://drive.google.com/drive/folders/1PsT9_HWX4snfgnhlwC6xM4rNjcoqXdk5?usp=drive_link
